Item
Model Highlights
Model Description
When Would You Select This Model
Actual Customer Rating
Unique Model Features
Maximum Size(with or without std. aluminum hood)
Maximum size with semi cassette hood (SC) or full cassette (FC)
Unit Projection Range
Mounting Options
Standard Unit Operation
Width Ordering Increments
Main Frame Components Origin
Product Assembly
Frame Warranty (Non Prorated)
Fabric Warranty (Non Prorated)
Platinum Protection Availability
Platinum Protection PLUS Availability
Model Options
Frame Colors
Fabric Options
Front Drop Shade (motorized or manual operated)
Lighting
Electronic Options
Technical Data
Arm Tension System
Arm Elbow Construction
Arm Cycle Life Expectancy
Arm Tension Closing Force (per arm)
Arm Spring Tension
Wind Class Rated
Unit Weight (Per Foot)
Arm Shoulder Construction
Torsion Bar Standard
Solar Eclipse
Ultra Premium Grade Cassette Style Lateral Arm
Clean Sleek European Design
5.0 Out Of 5.0
Compact Design, Semi And Full Cassette With Drop Shade Option
23' Wide X 13'0" Projection
23' Wide X 13'0" Projection
(4) 8'2", 10'6", 11'6", 13'0"
Wall, Soffit, Roof
Plug-in Motor With Override Motor Feature, Remote Controlled
By The 1/4 Inch
Spain & USA
USA
Lifetime
10 Years
Included At No Additional Charge
Yes
Alpine & Onyx
100% Acrylic Sunbrella Shade Fabric, 150+ Patterns & Colors
Up To 23' Wide X 11'6" Projection
Dimmable LED Only
Wind Sensor, Sun Sensor, Rain Sensor, Wireless Wall Switches, Multi Channel Transmitters, App Controlled Connectivity
10 Cable ABT Belt System
Cast Aluminum, Sealed Bearings, Concealed Belt
72,000 Cycles
325 Lbs.
920 Lbs
Class III Rated 81lbs/30 Mph
22 Lbs
Two Piece Forged Design - 4 Lbs. Each
1.58" X 1.58" (40mm X 40mm) X .150" Thick - Aluminum
The Eclipse Premier
Ultra Premium Grade Lateral Arm
More Rugged System With A Longer Projection Option
4.9 Out Of 5.0
Conceal Arm Belt And Seal Bearing Elbows For A Quieter And Smooth Operation
Up To 40' Wide X 13' Projection
SC - Up To 23' Wide X 13' Projection
(5) 6'7", 8'2", 10'6", 11'6", 13'0"
Wall, Soffit, Roof
Plug-in Motor With Override Motor Feature, Remote Controlled
By The 1/4 Inch
Spain & USA
USA
Lifetime
10 Years
Included At No Additional Charge
Yes
White, Camel, Spartan Bronze, Onyx
100% Acrylic Sunbrella Shade Fabric, 150+ Patterns & Colors
Up To 22' Wide X 13' Projection - Not Available With SC
Rope Lighting Or Dimmable LED
Wind Sensor, Sun Sensor, Rain Sensor, Wireless Wall Switches, Multi Channel Transmitters, App Controlled Connectivity
10 Cable ABT Belt System
Cast Aluminum, Sealed Bearings, Concealed Belt
72,000 Cycles
325 Lbs.
920 Lbs.
Up To Class III Rated 81lbs/30 Mph
17 Lbs.
Cast/extruded Design - 4 Lbs. Each
1.58" X 1.58" (40mm X 40mm) X .150" Thick - Aluminum
Total Eclipse
Heavy Duty Lateral Arm
Very Windy Situations Or For Maximum Projection
4.1 Out Of 5.0
Largest Projection Lateral Arm You Can Buy In The States
Up To 40' Wide X 16'6" Projection
N/A
(2) 14'9", 16'6"
Wall, Soffit, Roof
Plug-in Motor With Override Motor Feature, Remote Controlled
By The 1/4 Inch
Spain & USA
USA
Lifetime
10 Years
Included At No Additional Charge
Yes
White, Camel, Spartan Bronze
100% Acrylic Sunbrella Shade Fabric, 150+ Patterns & Colors
Up To 22' Wide X 16'6" Projection
Rope Lighting Or Dimmable LED
Wind Sensor, Sun Sensor, Rain Sensor, Wireless Wall Switches, Multi Channel Transmitters, App Controlled Connectivity
11 Cable ABT Belt System
Cast Aluminum, Bronze Bushings, Exposed Belt
60,000 Cycles
400 Lbs.
1800 Lbs.
Up To Class III Rated 81lbs/30 Mph
20 Lbs.
Three Piece Cast Design - 8 Lbs. Each
2.0" (50mm) X .125" - Steel, Optional Aluminum
The Eclipse
Premium Grade Lateral Arm
Basic Sun Protection
4.8 Out Of 5.0
Cross Arm Configurations For Narrow Widths And Longer Projections
Up To 40' X 11'6" Projection
SC - Up To 22' Wide X 11'6" Projection
(5) 5'0", 7'4", 9'0", 10'6", 11'6"
Wall, Soffit, Roof
Plug-in Motor With Override Motor Feature, Remote Controlled
By The 1/4 Inch
Spain & USA
USA
10 Years
10 Years
Yes
Yes
White, Camel, Spartan Bronze
100% Acrylic Sunbrella Shade Fabric, 150+ Patterns & Colors
Up To 22' Wide X 11'6" Projection
Rope Lighting Or Dimmable LED
Wind Sensor, Sun Sensor, Rain Sensor, Wireless Wall Switches, Multi Channel Transmitters, App Controlled Connectivity
9 Cable ABT Belt System
Cast Aluminum, Bronze Bushings, Exposed Belt
60,000 Cycles
311 Lbs.
890 Lbs.
Up To Class III Rated 81lbs/30 Mph
15 Lbs.
Two Piece Cast Design 3 Lbs. Each
1.58" X 1.58" (40mm X 40mm) X .150" Thick - Aluminum
motor and electronics.
